Secure Door Control Module DS-K2M061

DS-K2M061 Secure Door Control Unit is the interlayer between the access control terminal and the lock, including the door magnetic, the lock, the exit button and so on. It can be applied to keep the door closed when the door is damaged

Features

Communicates with the access control terminal via RS-485 to execute the commands from the terminal including open door, close door, normally open and normally closed

Collects the door magnetic signal, the exit button signal and the tamper-proof signal and send them to the access control terminal

Supports tampering alarm

Supports RS-485 communication indicators to show the communication status

4-ch DIP switch supporting ID No. configuration

Supports a Wiegand interface to connect a Wiegand card reader to enter/exist access control terminal by swiping card

Fire interface and exit button linkage

Specifications

Interface

Lock control: 1

Exit button: 1

Door contact input: 1

Alarm input: 2

Alarm output: 1 RS-485 1

Wiegand: 1

General

Indicator: 1 for power supply

Power supply: 12 VDC

Working temperature: -40 °C to 70 °C

Working humidity: 0% to 90%

Dimensions: 48 mm × 115 mm × 26 mm (1.9" × 4.5" × 1.0")

Installation: Wall Mounting
