Yamaha M-5000 Stereo Amplifier

Audio Specifications

Input Terminal

RCA: 1

Bal: 1

Trigger In: 1

Output Terminal

Trigger Out: 1

Rated Output Power

100 W + 100 W (8 ohm, 20 Hz-20 kHz, 0.07% THD, 2-ch driven), 200 W + 200 W (4 ohm, 20 Hz-20 kHz, 0.07% THD, 2-ch driven), 400 W (8 ohm, 20 Hz-20 kHz, 0.07% THD, Monaural driven)

Dynamic Power Per Channel

[IHF] 125 W + 125 W (8 ohm), 170 W + 170 W (6 ohm), 250 W + 250 W (4 ohm), 500 W + 500 W (2 ohm)

Dynamic Headroom

0.97 dB (8 ohm)

Maximum Output Power

220 W + 220 W (4 ohm, 1 kHz, 0.7% THD)

IEC Output Power

125 W + 125 W (8 ohm, 1 kHz, 0.02% THD)

Maximum Effective Output Power

[JEITA, 1kHz, 10% THD]135 W + 135 W (8 ohm), 270 W + 270 W (4 ohm)

Power Bandwidth

10 Hz-50 kHz (8 ohm, 0.1% THD, 45 W)

Damping Factor

300 or higher (8 ohm, 1 kHz)

Input Sensitivity / Input Impedance

(BAL) 2.0 Vrms / 47 kohm, (LINE) 1.0 Vrms / 47 kohm [1 kHz 100 W / 8 ohm conversion]

Maximum Input Signal Voltage

(BAL) 2.20 Vrms [1 kHz, 0.5% THD], (LINE) 1.10 Vrms [1 kHz, 0.5% THD]

Frequency Response

+0 dB / -3 dB (5 Hz-100 kHz), +0 dB / -0.3 dB (20 Hz-20 kHz)

Total Harmonic Distortion Plus Noise

2ch driven: 0.035% (LINE [BAL] to SP Out, 20 Hz-20 kHz, 50 W, 8 ohms), Monaural driven: 0.05% (LINE [BAL] to SP Out, 20 Hz-20 kHz, 200 W, 8 ohms)

Channel Separation

90 dB or higher (1 kHz, Input 1.0 kohm Terminated), 70 dB or higher (10 kHz, Input 1.0 kohm Terminated)

Signal-to-Noise Ratio

[IHF-A network, Input 1 kohm shorted] 110 dB

Residual Noise
