USB Face Enrollment Camera DS-2CS55D7B

Features

Video Camera

2 million wide dynamic USB micro camera

Sensor Type: 2.0 Mega Progressive Scan CMOS

Effective Pixels: 1920(horizontal)×1080(vertical)

Signal System: PAL/NTSC

Minimum Illumination: 0.1Lux @(F1.2, AGC ON)

Shutter: 1/25 (1/30) second to 1/15,000 second

Lens: 2.1mm @F2.2 Field of view: horizontal 137°, vertical 80°, diagonal 162°
2.8mm @F2.2 Field of view: horizontal 115°, vertical 60°, diagonal 142°
3.6mm @F2 .2 Field of view: horizontal 91°, vertical 49°, diagonal 107°
6mm @F2.2 Field of view: horizontal 60°, vertical 32°, diagonal 70°

Outgoing Wire Length: 2m

Lens interface type: M12

Specifications

Video Camera

Day and night conversion mode: Single color

Wide dynamic range: Greater than 120dB

Synchronously: Internal synchronization

Video frame rate: 1920×1080@30fps 1920×1080@25fps 1280×960@30fps 1280×960@25fps
1280×720@30fps 1280×720@25fps 800×600@30fps 800×600@25fps
640×480@30fps 640×480@25fps 352×288@30fps 352×288@25fps
320×240@30fps 320×240@25fps 160×120@30fps 160×120@25fps

Signal to noise ratio: Greater than 62Db

Interface

Video output: USB 2.0

General Specification

Working temperature and humidity:-30℃~70℃, humidity less than 90% (no condensation)

Power Supply: DC5V±10% (USB interface)

Power consumption: 1.5W MAX

Size(mm): 40.9×34.5×31

Weight: 150g
